Image Sensor Type
|
Color CCD (Charge-coupled device) x 3 (front x 1, back x 1, Flatbed x 1)
|
|
Light Source
|
White LED Array x 6 (front x 2, back x 2, Flatbed x 2)
|
|
Multifeed Detection
|
Ultrasonic multi-feed detection sensor, Paper detection sensor
|
|
Optical Resolution
|
600 dpi
|
|
Output resolution(1)
|
Color (24-bit)
|
50 to 600 dpi
(adjustable by 1 dpi increments), 1,200 dpi (driver)(2)
|
|
Grayscale (8-bit)
|
|
Monochrome
|
|
Output format
|
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
|
|
Internal Video Processing
|
4,096 levels (12-bit)
|
|
Image Processing Functions
|
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, De-Screen,Emphasis, Halftone, Dropout color (None / Red / Green / Blue / White / Saturation / Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Dither, Static threshold, Divide Long Page
|
|
Scanning Speed(3)
(A4 Landscape)
|
ADF
|
Color(4)
Grayscale(4)
Monochrome(5)
|
Simplex: 100 ppm, Duplex: 200 ipm
(200 dpi / 300 dpi)
|
|
Flatbed
|
Color(4)
Grayscale(4)
Monochrome(5)
|
0.6 Seconds (200 dpi / 300 dpi)
|
|
Scanning Speed(3)
(A4 Portrait)
|
ADF
|
Color(4)
Grayscale(4)
Monochrome(5)
|
Simplex: 80 ppm, Duplex: 160 ipm
(200 dpi / 300 dpi)
|
|
Flatbed
|
Color(4)
Grayscale(4)
Monochrome(5)
|
0.9 Seconds (200 dpi / 300 dpi)
|
|
Paper chute capacity (A4 Landscape)(6)
|
300 Sheets (A4: 80 g/m² or 20 lb.)
|
|
Background Colors
|
ADF
|
White / Black (switching with command available)
|
|
Flatbed
|
White (switching to optional black available)
|
|
Daily Duty Cycle
|
30,000 Pages
|
|
Document Size
|
Minimum
|
50.8 mm x 69 mm (2 in. x 2.72 in.)
|
|
Maximum
|
304.8 mm x 431.8 mm (12 in. x 17 in.)
|
|
Long page scanning(7)
(Maximum)
|
304.8 mm x 5,588 mm (12 in. x 220 in. )
|
|
Flatbed
(Maximum)
|
304.8 mm x 457.2 mm (12 in. x 18 in. )
|
|
Paper Weight
(Thickness)(8)
|
Paper
|
20 to 413 g/m² (5.3 to 110 lb.), A8 size: 128 to 209 g/m² (34 to 56 lb)
|
|
Plastic Card
|
Up to 1.4 mm (9)
|
|
Interface
|
USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1
|
|
Minimum PC Specification
|
CPU: Intel® Core i5 2400S @ 2.5Ghz
Memory: 4.0GB
OS:Windows® 7 SP1 (32-bit)
Software: PaperStream Capture
|
|
Physical Specifications
|
|
Power Requirements
|
100 to 240 VAC ± 10 %
|
|
Power Consumption
|
Operating: 64 W or less, Sleep mode: 1.7 W or less, Auto Standby(OFF) mode: Less than 0.35 W
|
|
Dimensions (WxDxH)(10)
|
706 mm x 500 mm x 345 mm (27.8 in. x 19.7 in. x 13.6 in.)
|
|
Weight
|
35 kg (77.2 lb.) or less
|
|
Environmental Compatibility
|
ENERGY STAR® / RoHS
|
|
Operating Environment
|
Temperature
|
5 °C to 35 °C (41 °F to 95 °F )
|
|
Relative Humidity
|
20 % - 80 % (non-condensing)
|
|
Included Items
|
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
|
|
Included Software / Drivers
|
PaperStream IP (TWAIN/ISIS) ,2D Barcode for PaperStream(11), Software Operation Panel, Error Recovery Guide, PaperStream Capture, ScanSnap Manager for fi Series(11), Scan to Microsoft SharePoint(11), ABBYY FineReader for ScanSnap(11), Scanner Central Admin
|
|
Options
|
Black Document Pad (fi-575BK)
|
|
Supported Operating Systems
|
Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit), Windows Server® 2008 (32-bit/64-bit)
|
